SKLA36AT1200 General Electric / GE Molded Case Circuit Breakers

Name: SKLA36AT1200 General Electric / GE Molded Case Circuit Breakers
Brand: General Electric / GE
Price: 3861.0 USD
Availability: InStock

Item # SKLA36AT1200

NOTE: Images are for Reference Only

Product Specifications

Type: SKLA
Amperage: 1200
Poles: 3
Voltage: 600

SKLA36AT1200 Description

ELECTRONIC SOLID STATE TRIP, MOLDED CASE TYPE; 8.25 INCH W X 5.5 INCH D X 15.5 INCH H SIZE; 690 V MAX. AC VOLTAGE RATING; UL 489, CSA C22.2 APPROVAL; 240/480/600 VAC (UL/CSA); 220 TO 240/380 TO 415/500/690 VAC (IEC) VOLTAGE RATING; 100 KILOAMPERE AT 240 VAC, 65 KILOAMPERE AT 480 VAC, 42 KILOAMPERE AT 600 VAC (UL); 100 KILOAMPERE AT 220 TO 240 VAC, 65 KILOAMPERE AT 380 TO 415, 42 KILOAMPERE AT 500 VAC, 14 KILOAMPERE AT 690 VAC (IEC) INTERRUPTING RATING; 1200 AMPERE CURRENT RATING; 3 POLE(S); NOT INCLUDED TERMINAL TYPE; SK FRAME TYPE; SPECTRA[R] BRAND; INCLUDES LONG/SHORT/INSTANTANEOUS TIME TRIP; SKL MODEL Molded Case Circuit Breakers from General Electric / GE

Relectric Recommends RE-Certified Plus

RE-Certified

Re-Certified products have been previously energized and have undergone a detailed 12-point quality inspection and testing process to ensure the electrical, mechanical, and electromechanical components are functioning properly. RE-Certified products are suitable for use as field replacements, retrofits, upgrades, and expansions. We test each of our RE-Certified products to industry standards and certify them to be operational when installed. RE-Certified products come with a Full 1-Year No-Hassle Warranty.

RE-Certified Plus

RE-Certified Plus products include additional quality control checks. RE-Certified Plus products are tested to NETA Specifications and have Restorative Screening performed. RE-Certified Plus products have a 100% Money Back Guarantee. RE-Certified Plus products have a Full 2-Year No-Hassle Warranty.

NETA Testing

Relectric offers NETA testing on all products. Testing performed by RESA Power Service, a NETA Accredited Company. NETA testing fees vary by product.

Summary

The SKLA36AT1200 General Electric / GE Molded Case from Relectric

Relectric stocks new and used SKLA36AT1200 General Electric / GE Molded Case and many more brand-name electrical supplies. All of our reconditioned SKLA36AT1200 General Electric / GE Molded Case have been professionally tested and certified, and we guarantee their performance. You can also order your SKLA36AT1200 General Electric / GE Molded Case configured to your specifications. Relectric also carries a large stock of replacement parts for the SKLA36AT1200 General Electric / GE Molded Case. Contact one of our sales consultants today.

Buy Now

RE-Certified more info

INSPECTED & TESTED
1 Year Warranty

$3,861.00

10 in stock
RE-Certified Plus more info

RESA Certified
2 Year Warranty

$5,019.30

Call for availability
New Surplus more info

Guaranteed New
1 Year Warranty

$7,275.00

Call for availability

Qty

Request A Quote

Do you need a quote for this or a similar product? Do you have a question or need more detail about this product?

Request Quote or Info

Extended Details

Description:: 600 VAC, 1200 A Sensor, 65 kA Interrupt, 3-Pole, (4) 250 to 500 KCMIL Aluminum, SK1200 Frame, Digital, Solid State Electronic/Interchangeable Trip, RMS Trip Unit, LSI Trip Function, Standard Continuous Load, Molded Case Circuit Breaker
Type:: Molded Case, Electronic Solid State Trip
Frame Type:: K
Voltage Rating:: 600 V
Maximum AC Voltage Rating:: 690 V
Current Rating:: 1200 Ampere

Features and Benefits

Features/Benefits:: Spectra RMS Molded Case Circuit Breakers (SE150, SF250, SG600 and SK1200) have a Digital, Solid State, RMS Sensing Trip System with Field Installable, Front-Mounted Rating Plugs to Establish or Change the Breaker Ampere Rating; Adjustable Instantaneous with Tracking Short-Time is Standard on All Frames; The Trip System Uses Digital Sampling to Determine the RMS Value of Sinusoidal and Non-Sinusoidal Currents
Additional Information:: 600 VAC, 1200 A Sensor, 65 kA Interrupt, 3-Pole, (4) 250 to 500 KCMIL Aluminum, SK1200 Frame, Digital, Solid State Electronic/Interchangeable Trip, RMS Trip Unit, LSI Trip Function, Standard Continuous Load, Molded Case Circuit Breaker
