NEB3B090B Siemens / ITE Molded Case Circuit Breakers
Item # NEB3B090B

NEB3B090B

NOTE: Images are for Reference Only

Product Details and Specifications

Type NEB
Amperage 90
Poles 3
Voltage 600

NEB3B090B Description

BREAKER NEB 3P 90A 480V 35KA LOAD LUGS Molded Case Circuit Breakers from Siemens / ITE

Relectric Recommends RE-Certified Plus

RE-Certified

Re-Certified products have been previously energized and have undergone a detailed 12-point quality inspection and testing process to ensure the electrical, mechanical, and electromechanical components are functioning properly. RE-Certified products are are suitable for use as field replacements, retrofits, upgrades, and expansions. We test each of our RE-Certified products to industry standards and certify them to be operational when installed. RE-Certified products come with a Full 1-Year No-Hassle Warranty.

RE-Certified Plus

RE-Certified Plus products include additional quality control checks. RE-Certified Plus products are tested to NETA Specifications and have Restorative Screening performed. RE-Certified Plus products have a 100% Money Back Guarantee. RE-Certified Plus products have a Full 2-Year No-Hassle Warranty.

NETA Testing

Relectric offers NETA testing on all products. Testing performed by RESA Power Service, a NETA Accredited Company. NETA testing fees vary by product.

Buy Now

Call For Best Price

Ships in 0-2 Working Days

Call For Best Price

Ships in 0-2 Working Days

Call For Best Price

Ships in 0-2 Working Days

Request A Quote

Do you need a quote for this or a similar product? Do you have a question or need more detail about this product?
Request Quote or Information

Extended Details

240/347/480/600 VAC 50/60 Hz, 125/250 VDC, 90 A, 85 kA, 3-Pole, Thermal Magnetic Trip Unit, Panelboard Circuit Breaker
Thermal Magnetic, Molded Case
480 Volt
90 Ampere at 40 Deg C
3
85 Kiloamp at 240 Volt AC (UL 489), 35 Kiloamp at 480 Volt AC/125/250 Volt DC (UL 489), 22 Kiloamp at 600 Star/347 Volt AC (UL 489), 85 Kiloamp at 240 Volt AC (IEC), 40 Kiloamp at 415 Volt AC (IEC), 35 Kiloamp at 250 Volt DC (IEC)

Features and Benefits

Frame Type EG; Terminal Type Load Lug; Overall Dimension 3 Inch Width x 3 Inch Depth x 5.5 Inch Height

Ask an expert

Ask An Expert

Our experts can help.

800.497.6255

Email

Summary

The NEB3B090B Siemens / ITE Molded Case from Relectric

Relectric stocks new and used NEB3B090B Siemens / ITE Molded Case and many more brand-name electrical supplies. All of our reconditioned NEB3B090B Siemens / ITE Molded Case have been professionally tested and certified, and we guarantee their performance. You can also order your NEB3B090B Siemens / ITE Molded Case configured to your specifications. Relectric also carries a large stock of replacement parts for the NEB3B090B Siemens / ITE Molded Case. Contact one of our sales consultants today.
