HMCPS030H1C Eaton / Cutler-Hammer / Westinghouse Molded Case Circuit Breakers

Item # HMCPS030H1C

HMCPS030H1C
  • HMCPS030H1C
  • HMCPS030H1C
  • HMCPS030H1C
  • HMCPS030H1C

NOTE: Images are for Reference Only

Product Specifications

Type
HMCP
Amperage
30
Poles
3
Voltage
600

HMCPS030H1C Description

SERIES C, F-FRAME MOTOR CIRCUIT PROTECTOR 3P 30A CB Molded Case Circuit Breakers from Eaton / Cutler-Hammer / Westinghouse

Features and Benefits

Additional Information:
Molded Case Circuit Breaker Motor Circuit Protector; Type Magnetic; Voltage Rating 600 Volt AC, 250 Volt DC; Maximum AC Voltage Rating 600 Volt; Maximum DC Voltage Rating 250 Volt; Current Rating 30 Amp; Number of Poles 3; Trip Setting 90 to 300 Amp; Starter Size NEMA 1; Motor FLA 6.9 to 25.2 Amp; Terminal Type Non-Aluminum Line and Load; Size 5 Inch Width x 8 Inch Depth x 5 Inch Height; Approval UL 489, CSA C22.2, CE; Applicable Standard IEC 157-1
