Loading Circuit Breaker Detail

HJL36070 Square D / Schneider Electric Molded Case Circuit Breakers

Item # HJL36070

NOTE: Images are for Reference Only

Product Specifications

Type
HJL
Amperage
70
Poles
3
Voltage
600
Short Circ Int Cap
65kA@480V
Configuration
Line + Load Lugs

HJL36070 Description

Square D, Molded Case, Circuit Breaker, PowerPact H, Type HJL, 70A, 3P, 600VAC, Line + Load Lugs, 14-3/0 AWG Al/Cu, Thermal Magnetic, 80% Rated, Interrupting Current 100k at 240V / 65k at 480V / 25k at 600V Molded Case Circuit Breakers from Square D / Schneider Electric
