HFD2045 Eaton / Cutler-Hammer / Westinghouse Molded Case Circuit Breakers

Item # HFD2045

HFD2045
  • HFD2045
  • HFD2045

NOTE: Images are for Reference Only

Product Specifications

Type
HFD
Amperage
45
Poles
2
Voltage
600
Short Circ Int Cap
65kA@480V
Grouping
HFD-65k

HFD2045 Description

SERIES C F-FRAME MOLDED CASE CIRCUIT BREAKER TYPE HFD 2 POLE 45A T Molded Case Circuit Breakers from Eaton / Cutler-Hammer / Westinghouse

Features and Benefits

Additional Information:
Non-Interchangeable Trip Circuit Breaker; Type Fixed Thermal Magnetic, Molded Case; Frame Type FD; Voltage Rating 600 Volt AC 50/60 Hertz, 250 Volt DC; Maximum AC Voltage Rating 600 Volt; Maximum DC Voltage Rating 250 Volt; Current Rating 45 Amp at 40 Deg C; Number of Poles 2; Interrupting Rating 100 Kiloamp at 240 Volt AC, 65 Kiloamp at 480 Volt AC, 25 Kiloamp at 600 Volt AC, 22 Kiloamp at 250 Volt DC (UL), 100 Kiloamp at 220/240 Volt AC, 65 Kiloamp at 380/415/440 Volt AC, 25 Kiloamp at 500 Volt AC, 22 Kiloamp at 250 Volt DC (IEC); Terminal Type Load; Size 2.75 Inch Width x 3.88 Inch Depth x 6 Inch Height; Approval UL 489, CSA C22.2; Application HACR, Switchboard; Applicable Standard IEC 60947-2, SABS 156, SEV 157-1, NFC 63-120, VDE0660, Federal Specification W-C-375b 22a
