America's First Call for Commercial / Industrial Circuit Breakers & Other Electrical Parts.

FD3100K Eaton / Cutler-Hammer / Westinghouse Molded Case Circuit Breakers

Item # FD3100K

FD3100K
  • FD3100K
  • FD3100K
  • FD3100K

NOTE: Images are for Reference Only

Product Specifications

Type
FD
Amperage
100
Poles
3
Voltage
600
Short Circ Int Cap
35kA@480V

FD3100K Description

CHR; 100A; 3P; 600V; Type FD Molded Case Circuit Breakers from Eaton / Cutler-Hammer / Westinghouse

Features and Benefits

Features/Benefits:
All Eaton's F-Frame Circuit Breakers are HACR Rated; All F-Frame Circuit Breakers are Suitable for Reverse Feed Use
Additional Information:
600 VAC 50/60 Hz, 250 VDC, 100 A, 35/10 kA, 3-Pole, Load Side Terminal, FD Frame, Molded Case Switch, Non-Interchangeable Trip Circuit Breaker
