FD3050 Eaton / Cutler-Hammer / Westinghouse Molded Case Circuit Breakers
Item # FD3050

FD3050
FD3050
FD3050

NOTE: Images are for Reference Only

Product Details and Specifications

Type FD
Amperage 50
Poles 3
Voltage 600
Short Circ Int Cap 35kA@480V
Configuration Bolt-On

FD3050 Description

Eaton, Molded Case, Circuit Breaker, Type FD, 50A, 3P, 600VAC, Bolt-On, Thermal Magnetic, Interrupting Current: 35kA at 480VAC Molded Case Circuit Breakers from Eaton / Cutler-Hammer / Westinghouse

Relectric Recommends RE-Certified Plus

RE-Certified

Re-Certified products have been previously energized and have undergone a detailed 12-point quality inspection and testing process to ensure the electrical, mechanical, and electromechanical components are functioning properly. RE-Certified products are are suitable for use as field replacements, retrofits, upgrades, and expansions. We test each of our RE-Certified products to industry standards and certify them to be operational when installed. RE-Certified products come with a Full 1-Year No-Hassle Warranty.

RE-Certified Plus

RE-Certified Plus products include additional quality control checks. RE-Certified Plus products are tested to NETA Specifications and have Restorative Screening performed. RE-Certified Plus products have a 100% Money Back Guarantee. RE-Certified Plus products have a Full 2-Year No-Hassle Warranty.

NETA Testing

Relectric offers NETA testing on all products. Testing performed by RESA Power Service, a NETA Accredited Company. NETA testing fees vary by product.

Buy Now

$569.46

3 in stock

$740.30

Ships in 0-2 Working Days

$795.00

Ships in 0-2 Working Days

Call For Best Price

Ships in 0-2 Working Days

Request A Quote

Do you need a quote for this or a similar product? Do you have a question or need more detail about this product?
Request Quote or Information

Extended Details

600 VAC 50/60 Hz, 250 VDC, 50 A, 65/35 kA Interrupt Rating, 3-Pole, F-Frame, Load Side Terminal, Fixed Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
Molded Case, Fixed Thermal Magnetic
F
600 Volt AC 50/60 Hertz, 250 Volt DC
600 Volt
250 Volt

Features and Benefits

All Eaton's F-Frame Circuit Breakers are HACR Rated; All Circuit Breakers 10 Through 30 Amperes are Suitable for HID (High Intensity Discharge) Use; All F-Frame Circuit Breakers are Suitable for Reverse Feed Use
Application Panelboard, Switchboard, Motor Control Center, HACR; Applicable Standard NEMA AB1, AS 2184, BS 4752, IEC 157-1, SABS 156, SEV 157-1, VDE 0660, Federal Specification W-C-375b 22a
