FD2080V Eaton / Cutler-Hammer / Westinghouse Molded Case Circuit Breakers

Item # FD2080V

FD2080V
  • FD2080V
  • FD2080V
  • FD2080V

NOTE: Images are for Reference Only

Product Specifications

Type
FD
Amperage
80
Poles
2
Voltage
600
Short Circ Int Cap
35kA@480V

FD2080V Description

Molded Case, Thermal Magnetic; F-Frame, Series C; 600 VAC AT 50/60 Hz, 250 VDC; 80A AT 50 DEG C; 2P; Interrupting Rating 65kA AT 240 VAC, 35kA AT 480 VAC, 18kA AT 600 VAC, 10kA AT 250 VDC; 65kA AT 220/240 VAC, 35kA AT 380/415/440 VAC, 18kA AT 500 VAC, 10kA AT 250 VDC; Load Side Lugs; Size 2.75 Inch W X 3.375 Inch D X 6 Inch H; FD Model Molded Case Circuit Breakers from Eaton / Cutler-Hammer / Westinghouse

Features and Benefits

Features/Benefits:
F-Frame Circuit Breakers are HACR Rated; All Circuit Breakers 10 Through 30 Amperes are Suitable for HID (High Intensity Discharge) Use; All F-Frame Circuit Breakers are Suitable for Reverse Feed Use
Additional Information:
600 VAC 50/60 Hz, 250 VDC, 80 A, 35 kA, 2-Pole, FD Frame, Non-Interchangeable Trip Thermal Magnetic, Molded Case Circuit Breaker with 50 Deg C calibration
