EHD3060L Eaton / Cutler-Hammer / Westinghouse Molded Case Circuit Breakers

Item # EHD3060L

EHD3060L
  • EHD3060L
  • EHD3060L
  • EHD3060L

NOTE: Images are for Reference Only

Product Specifications

Type
EHD
Amperage
60
Poles
3
Voltage
480
Short Circ Int Cap
14kA@480V
Configuration
Feed-Thru
Feature 1
LI Functions

EHD3060L Description

Eaton, Molded Case, Circuit Breaker, Series C, Type EHD, 60A, 3P, 3PH, 480V, Thermal Magnetic, Feed-Thru, Line + Load Lugs, Interrupting Current: 14kA at 480V, Long Time & Instantaneous (LI) Trip Functions Molded Case Circuit Breakers from Eaton / Cutler-Hammer / Westinghouse

Features and Benefits

Features/Benefits:
All Eaton's F-Frame Circuit Breakers are HACR Rated; All F-Frame Circuit Breakers are Suitable for Reverse Feed Use
Additional Information:
480 VAC 50/60 Hz, 250 VDC, 60 A, 14/10 kA, 3-Pole, Line and Load Terminal, EHD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
