EHD1040L Eaton / Cutler-Hammer / Westinghouse Molded Case Circuit Breakers
Item # EHD1040L

EHD1040L
EHD1040L

NOTE: Images are for Reference Only

Product Details and Specifications

Type EHD
Amperage 40
Poles 1
Voltage 277
Short Circ Int Cap 14kA@277V

EHD1040L Description

SERIES C F-FRAME MOLDED CASE CIRCUIT BREAKER 1P 40A CB Molded Case Circuit Breakers from Eaton / Cutler-Hammer / Westinghouse

Relectric Recommends RE-Certified Plus

RE-Certified

Re-Certified products have been previously energized and have undergone a detailed 12-point quality inspection and testing process to ensure the electrical, mechanical, and electromechanical components are functioning properly. RE-Certified products are are suitable for use as field replacements, retrofits, upgrades, and expansions. We test each of our RE-Certified products to industry standards and certify them to be operational when installed. RE-Certified products come with a Full 1-Year No-Hassle Warranty.

RE-Certified Plus

RE-Certified Plus products include additional quality control checks. RE-Certified Plus products are tested to NETA Specifications and have Restorative Screening performed. RE-Certified Plus products have a 100% Money Back Guarantee. RE-Certified Plus products have a Full 2-Year No-Hassle Warranty.

NETA Testing

Relectric offers NETA testing on all products. Testing performed by RESA Power Service, a NETA Accredited Company. NETA testing fees vary by product.

Buy Now

Call For Best Price

Out of stock

Call For Best Price

Out of stock

Call For Best Price

Out of stock

Request A Quote

Do you need a quote for this or a similar product? Do you have a question or need more detail about this product?
Request Quote or Information

Extended Details

Non-Interchangeable Trip Circuit Breaker; Type Fixed Thermal Magnetic, Molded Case; Frame Type FD; Voltage Rating 277 Volt AC 50/60 Hertz, 125 Volt DC; Maximum AC Voltage Rating 277 Volt; Maximum DC Voltage Rating 125 Volt; Current Rating 40 Amp at 40 Deg C; Number of Poles 1; Interrupting Rating 4 Kiloamp at 277 Volt AC, 10 Kiloamp at 125 Volt DC (UL), 14 Kiloamp at 380/415 Volt AC, 10 Kiloamp at 125 Volt DC (IEC); Terminal Type Line and Load; Size 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height; Approval UL 489, CSA C22.2; Application HACR, Switchboard; Applicable Standard IEC 60947-2, SABS 156, SEV 157-1, NFC 63-120, VDE0660, Federal Specification W-C-375b 13a
Fixed Thermal Magnetic, Molded Case
FD
277 Volt AC 50/60 Hertz, 125 Volt DC
277 Volt
125 Volt

Features and Benefits

Application HACR, Switchboard; Applicable Standard IEC 60947-2, SABS 156, SEV 157-1, NFC 63-120, VDE0660, Federal Specification W-C-375b 13a

Ask an expert

Ask An Expert

Our experts can help.

800.497.6255

Email

Summary

The EHD1040L Eaton / Cutler-Hammer / Westinghouse Molded Case from Relectric

Relectric stocks new and used EHD1040L Eaton / Cutler-Hammer / Westinghouse Molded Case and many more brand-name electrical supplies. All of our reconditioned EHD1040L Eaton / Cutler-Hammer / Westinghouse Molded Case have been professionally tested and certified, and we guarantee their performance. You can also order your EHD1040L Eaton / Cutler-Hammer / Westinghouse Molded Case configured to your specifications. Relectric also carries a large stock of replacement parts for the EHD1040L Eaton / Cutler-Hammer / Westinghouse Molded Case. Contact one of our sales consultants today.
