EDB14050 Square D / Schneider Electric Miniature Circuit Breakers

Name: EDB14050 Square D / Schneider Electric Miniature Circuit Breakers
Brand: Square D / Schneider Electric
Price: 45.0 USD
Availability: InStock

Item # EDB14050

NOTE: Images are for Reference Only

Product Specifications

Type: EDB
Amperage: 50
Poles: 1
Voltage: 277
Short Circ Int Cap: 18kA@277V
Mounting Type: Bolt-On
Accessories: HID Rated
Grouping: NF Panel

EDB14050 Description

Square D, Miniature, Circuit Breakers, Type EDB, E-Frame, 50A, 1P, 277 VAC, Bolt-On, 14-2/0 AWG Al/Cu, Thermal Magnetic, Interrupting Current 25kA at 240VAC / 18 kA at 480 VAC, For NF Panelboards, High Intensity Discharge (HID) Rated Miniature Circuit Breakers from Square D / Schneider Electric

Relectric Recommends RE-Certified Plus

RE-Certified

Re-Certified products have been previously energized and have undergone a detailed 12-point quality inspection and testing process to ensure the electrical, mechanical, and electromechanical components are functioning properly. RE-Certified products are suitable for use as field replacements, retrofits, upgrades, and expansions. We test each of our RE-Certified products to industry standards and certify them to be operational when installed. RE-Certified products come with a Full 1-Year No-Hassle Warranty.

RE-Certified Plus

RE-Certified Plus products include additional quality control checks. RE-Certified Plus products are tested to NETA Specifications and have Restorative Screening performed. RE-Certified Plus products have a 100% Money Back Guarantee. RE-Certified Plus products have a Full 2-Year No-Hassle Warranty.

NETA Testing

Relectric offers NETA testing on all products. Testing performed by RESA Power Service, a NETA Accredited Company. NETA testing fees vary by product.

Summary

The EDB14050 Square D / Schneider Electric Miniature from Relectric

Relectric stocks new and used EDB14050 Square D / Schneider Electric Miniature and many more brand-name electrical supplies. All of our reconditioned EDB14050 Square D / Schneider Electric Miniature have been professionally tested and certified, and we guarantee their performance. You can also order your EDB14050 Square D / Schneider Electric Miniature configured to your specifications. Relectric also carries a large stock of replacement parts for the EDB14050 Square D / Schneider Electric Miniature. Contact one of our sales consultants today.

Buy Now

RE-Certified more info

INSPECTED & TESTED
1 Year Warranty

$45.00

5 in stock
RE-Certified Plus more info

RESA Certified
2 Year Warranty

$58.50

Ships in 0-2 Working Days
New Surplus more info

Guaranteed New
1 Year Warranty

$94.97

6 in stock

Qty

Request A Quote

Do you need a quote for this or a similar product? Do you have a question or need more detail about this product?

Request Quote or Info

Extended Details

Description:: 277 VAC, 50 A, 18 kA, 1-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
Type:: Thermal Magnetic, Branch, Miniature
Voltage Rating:: 277 Volt AC
Current Rating:: 50 Amp
Number of Poles:: 1
Interrupting Rating:: 18 Kiloamp at 480 Star/277 Volt AC

Features and Benefits

Features/Benefits:: Short Circuit/Overload Protection; HACR Rated; RoHS/REACH Compliant; Mercury-Free
Additional Information:: 277 VAC, 50 A, 18 kA, 1-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
