JGL36200SA Square D / Schneider Electric Molded Case Circuit Breakers
Item # JGL36200SA

JGL36200SA
JGL36200SA

NOTE: Images are for Reference Only

Product Details and Specifications

Type JGL
Amperage 200
Poles 3
Voltage 600

JGL36200SA Description

MOLDED CASE CIRCUIT BREAKER 600V 200A Molded Case Circuit Breakers from Square D / Schneider Electric

Relectric Recommends RE-Certified Plus

RE-Certified

Re-Certified products have been previously energized and have undergone a detailed 12-point quality inspection and testing process to ensure the electrical, mechanical, and electromechanical components are functioning properly. RE-Certified products are are suitable for use as field replacements, retrofits, upgrades, and expansions. We test each of our RE-Certified products to industry standards and certify them to be operational when installed. RE-Certified products come with a Full 1-Year No-Hassle Warranty.

RE-Certified Plus

RE-Certified Plus products include additional quality control checks. RE-Certified Plus products are tested to NETA Specifications and have Restorative Screening performed. RE-Certified Plus products have a 100% Money Back Guarantee. RE-Certified Plus products have a Full 2-Year No-Hassle Warranty.

NETA Testing

Relectric offers NETA testing on all products. Testing performed by RESA Power Service, a NETA Accredited Company. NETA testing fees vary by product.

Buy Now

Call For Best Price

Out of stock

Call For Best Price

Out of stock

Call For Best Price

Out of stock

Request A Quote

Do you need a quote for this or a similar product? Do you have a question or need more detail about this product?
Request Quote or Information

Extended Details

600 VAC 50/60 Hz, 250 VDC, 200 A, 18 kA, 3-Pole, J-Frame, Line/Load Lug, Thermal Magnetic, Current Limiting, Adjustable, Molded Case Circuit Breaker with 110/130 V Shunt Trip
Thermal Magnetic, Current Limiting, Adjustable
J
600 Volt AC 50/60 Hertz, 250 Volt DC
600 Volt
250 Volt

Features and Benefits

Powerpact J-Frame Circuit Breakers are Designed to Protect Electrical Systems from Damage Caused by Overloads and Short Circuits; Powerpact J-Frame Circuit Breakers are Available with Either Thermal Magnetic or Micrologic Electronic Trip Protection Units; This Powerpact J-Frame Circuit Breaker Provides Thermal Magnetic Circuit Protection with a Breaking Capacity of 18 Kiloamp at 600 Volt AC; All Powerpact J-Frame Circuit Breakers are Equipped with Dual Break Rotating Contacts that Reduce the Amount of Peak Current During a Short Circuit Fault; All Powerpact Circuit Breakers have an Integral Push to Trip Button in the Cover to Manually Trip the Circuit Breaker; HACR Rated; RoHS/REACH Compliant; Mercury-Free; PVC-Free; Green Premium Product
RoHS/REACH Compliant; Trip Setting 1000 Amp (Low), 2000 Amp (High); Mounting Type Unit; Control Type Toggle; Terminal Wire Size 3/0 AWG to 350 KCMIL (Copper/Aluminum); Continuous Current Rating 80 Percent; Operation Ambient Air Temperature Rating 28 to 158 Deg F; Includes 110/130 Volt AC Shunt Trip; Application Distribution; Applicable Standard NOM 003, NEMA, IEC 60947-2

Ask an expert

Ask An Expert

Our experts can help.

800.497.6255

Email

Summary

The JGL36200SA Square D / Schneider Electric Molded Case from Relectric

Relectric stocks new and used JGL36200SA Square D / Schneider Electric Molded Case and many more brand-name electrical supplies. All of our reconditioned JGL36200SA Square D / Schneider Electric Molded Case have been professionally tested and certified, and we guarantee their performance. You can also order your JGL36200SA Square D / Schneider Electric Molded Case configured to your specifications. Relectric also carries a large stock of replacement parts for the JGL36200SA Square D / Schneider Electric Molded Case. Contact one of our sales consultants today.
