FD3150L Eaton / Cutler-Hammer / Westinghouse Molded Case Circuit Breakers
Item # FD3150L

FD3150L
FD3150L
FD3150L

NOTE: Images are for Reference Only

Product Details and Specifications

Type FD
Amperage 150
Poles 3
Voltage 600
Short Circ Int Cap 35kA@480V

FD3150L Description

Molded Case, Thermal Magnetic; F-Frame, Series C; 600 VAC AT 50/60 Hz, 250 VDC; 150A AT 40 DEG C; 3P; Interrupting Rating 65kA AT 240 VAC, 35kA AT 480 VAC, 18kA AT 600 VAC, 10kA AT 250 VDC; 65kA AT 220/240 VAC, 35kA AT 380/415/440 VAC, 18kA AT 500 VAC, 10kA AT 250 VDC; Line Side Lugs, Load Side Lugs; Size 4.125 Inch W X 3.375 Inch D X 6 Inch H; FD Model Molded Case Circuit Breakers from Eaton / Cutler-Hammer / Westinghouse

Relectric Recommends RE-Certified Plus

RE-Certified

Re-Certified products have been previously energized and have undergone a detailed 12-point quality inspection and testing process to ensure the electrical, mechanical, and electromechanical components are functioning properly. RE-Certified products are are suitable for use as field replacements, retrofits, upgrades, and expansions. We test each of our RE-Certified products to industry standards and certify them to be operational when installed. RE-Certified products come with a Full 1-Year No-Hassle Warranty.

RE-Certified Plus

RE-Certified Plus products include additional quality control checks. RE-Certified Plus products are tested to NETA Specifications and have Restorative Screening performed. RE-Certified Plus products have a 100% Money Back Guarantee. RE-Certified Plus products have a Full 2-Year No-Hassle Warranty.

NETA Testing

Relectric offers NETA testing on all products. Testing performed by RESA Power Service, a NETA Accredited Company. NETA testing fees vary by product.

Buy Now

Call For Best Price

4 in stock

Call For Best Price

Ships in 0-2 Working Days

Call For Best Price

Ships in 0-2 Working Days

Request A Quote

Do you need a quote for this or a similar product? Do you have a question or need more detail about this product?
Request Quote or Information

Extended Details

600 VAC 50/60 Hz, 250 VDC, 150 A, 35/10 kA, 3-Pole, Line and Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
Molded Case, Thermal Magnetic
FD
600 Volt AC at 50/60 Hertz, 250 Volt DC
600 Volt
250 Volt

Features and Benefits

All Eaton's F-Frame Circuit Breakers are HACR Rated; All F-Frame Circuit Breakers are Suitable for Reverse Feed Use
Includes Terminal; Applicable Standard NEMA AB1, AS 2184, BS 4752, IEC 157-1, SABS 156, SEV 157-1, VDE 0660
