FD1025 Eaton / Cutler-Hammer / Westinghouse Molded Case Circuit Breakers
Item # FD1025

FD1025
FD1025

NOTE: Images are for Reference Only

Product Details and Specifications

Type FD
Amperage 25
Poles 1
Voltage 277
Short Circ Int Cap 35kA@277V

FD1025 Description

CHR; 25A; 1P; 277V; Type FD Molded Case Circuit Breakers from Eaton / Cutler-Hammer / Westinghouse

Relectric Recommends RE-Certified Plus

RE-Certified

Re-Certified products have been previously energized and have undergone a detailed 12-point quality inspection and testing process to ensure the electrical, mechanical, and electromechanical components are functioning properly. RE-Certified products are are suitable for use as field replacements, retrofits, upgrades, and expansions. We test each of our RE-Certified products to industry standards and certify them to be operational when installed. RE-Certified products come with a Full 1-Year No-Hassle Warranty.

RE-Certified Plus

RE-Certified Plus products include additional quality control checks. RE-Certified Plus products are tested to NETA Specifications and have Restorative Screening performed. RE-Certified Plus products have a 100% Money Back Guarantee. RE-Certified Plus products have a Full 2-Year No-Hassle Warranty.

NETA Testing

Relectric offers NETA testing on all products. Testing performed by RESA Power Service, a NETA Accredited Company. NETA testing fees vary by product.

Buy Now

Call For Best Price

Ships in 0-2 Working Days

Call For Best Price

Ships in 0-2 Working Days

Call For Best Price

Ships in 0-2 Working Days

Request A Quote

Do you need a quote for this or a similar product? Do you have a question or need more detail about this product?
Request Quote or Information

Extended Details

Non-Interchangeable Trip Circuit Breaker; Type Fixed Thermal Magnetic, Molded Case; Frame Type FD; Voltage Rating 277 Volt AC 50/60 Hertz, 125 Volt DC; Maximum AC Voltage Rating 277 Volt; Maximum DC Voltage Rating 125 Volt; Current Rating 25 Amp at 40 Deg C; Number of Poles 1; Interrupting Rating 35 Kiloamp at 277 Volt AC, 10 Kiloamp at 125 Volt DC (UL), 35 Kiloamp at 220/240Volt AC, 10 Kiloamp at 125 Volt DC (IEC); Terminal Type Load; Size 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height; Approval UL 489, CSA C22.2; Application HACR, Switchboard; Applicable Standard IEC 60947-2, SABS 156, SEV 157-1, NFC 63-120, VDE0660, Federal Specification W-C-375b 13a
Fixed Thermal Magnetic, Molded Case
FD
277 Volt AC 50/60 Hertz, 125 Volt DC
277 Volt
125 Volt

Features and Benefits

All Eaton's F-Frame Circuit Breakers are HACR Rated; All Circuit Breakers 10 through 30 Amp are Suitable for HID (High Intensity Discharge) Use
Application HACR, Switchboard; Applicable Standard IEC 60947-2, SABS 156, SEV 157-1, NFC 63-120, VDE0660, Federal Specification W-C-375b 13a

Ask an expert

Ask An Expert

Our experts can help.

800.497.6255

Email

Summary

The FD1025 Eaton / Cutler-Hammer / Westinghouse Molded Case from Relectric

Relectric stocks new and used FD1025 Eaton / Cutler-Hammer / Westinghouse Molded Case and many more brand-name electrical supplies. All of our reconditioned FD1025 Eaton / Cutler-Hammer / Westinghouse Molded Case have been professionally tested and certified, and we guarantee their performance. You can also order your FD1025 Eaton / Cutler-Hammer / Westinghouse Molded Case configured to your specifications. Relectric also carries a large stock of replacement parts for the FD1025 Eaton / Cutler-Hammer / Westinghouse Molded Case. Contact one of our sales consultants today.
