EDB36090 Square D / Schneider Electric Miniature Circuit Breakers
Item # EDB36090

NOTE: Images are for Reference Only

Product Details and Specifications

Type EDB
Amperage 90
Poles 3
Voltage 600Y/347
Short Circ Int Cap 14kA@600V
Mounting Type Bolt-On

EDB36090 Description

Square D, Circuit Breaker, Miniature, E-Frame, 90A, 3P, 600Y/347VAC, Bolt-On, 14-2/0 AWG Al/Cu, Thermal Magnetic, Interrupting Current 14kA at 600Y/347VAC, For NF Panelboards Miniature Circuit Breakers from Square D / Schneider Electric

Relectric Recommends RE-Certified Plus

RE-Certified

Re-Certified products have been previously energized and have undergone a detailed 12-point quality inspection and testing process to ensure the electrical, mechanical, and electromechanical components are functioning properly. RE-Certified products are are suitable for use as field replacements, retrofits, upgrades, and expansions. We test each of our RE-Certified products to industry standards and certify them to be operational when installed. RE-Certified products come with a Full 1-Year No-Hassle Warranty.

RE-Certified Plus

RE-Certified Plus products include additional quality control checks. RE-Certified Plus products are tested to NETA Specifications and have Restorative Screening performed. RE-Certified Plus products have a 100% Money Back Guarantee. RE-Certified Plus products have a Full 2-Year No-Hassle Warranty.

NETA Testing

Relectric offers NETA testing on all products. Testing performed by RESA Power Service, a NETA Accredited Company. NETA testing fees vary by product.

Buy Now

Call For Best Price

Call for availability

Call For Best Price

Call for availability

Call For Best Price

Call for availability

Request A Quote

Do you need a quote for this or a similar product? Do you have a question or need more detail about this product?
Request Quote or Information

Extended Details

600 Star/347 VAC, 90 A, 14 kA, 3-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
Thermal Magnetic, Branch, Miniature
600 Star/347 Volt AC
90 Amp
3
14 Kiloamp at 600 Star/347 Volt AC

Features and Benefits

Short Circuit/Overload Protection; HACR Rated; RoHS/REACH Compliant; Mercury-Free
RoHS/REACH Compliant; Overall Dimension 2.94 Inch Width x 4.05 Inch Depth x 5.66 Inch Height; Frame Type E; Terminal Type Lug Aluminum; Terminal Wire Size 12 to 2/0 AWG (Aluminum), 14 to 2/0 AWG (Copper); Operation Ambient Air Temperature Rating 104 Deg F

Ask an expert

Ask An Expert

Our experts can help.

800.497.6255

Email

Summary

The EDB36090 Square D / Schneider Electric Miniature from Relectric

Relectric stocks new and used EDB36090 Square D / Schneider Electric Miniature and many more brand-name electrical supplies. All of our reconditioned EDB36090 Square D / Schneider Electric Miniature have been professionally tested and certified, and we guarantee their performance. You can also order your EDB36090 Square D / Schneider Electric Miniature configured to your specifications. Relectric also carries a large stock of replacement parts for the EDB36090 Square D / Schneider Electric Miniature. Contact one of our sales consultants today.
